Ultra low-power crystal-based 32 kHz oscillator designed in TSMC 12FFC+
The OSC-XT-32k-T12FFC.01 IP is an ultra-low power crystal-based oscillator designed in TSMC 12 nm FF for accurate 32 kHz clock generation in the SoC Always-On domain (eg. implementation of RTC features). An embedded auxiliary loop controls the voltage amplitude at the crystal terminals for maximizing the power efficiency for multiple crystals. It enables to drive external crystal-dependent pulling capacitors, thus allowing to select the best trade-off between BoM and frequency accuracy. A bypass mode allows to drive an external clock through the IP to its output port.
查看 Ultra low-power crystal-based 32 kHz oscillator designed in TSMC 12FFC+ 详细介绍：
- 查看 Ultra low-power crystal-based 32 kHz oscillator designed in TSMC 12FFC+ 完整数据手册
- 联系 Ultra low-power crystal-based 32 kHz oscillator designed in TSMC 12FFC+ 供应商
Block Diagram of the Ultra low-power crystal-based 32 kHz oscillator designed in TSMC 12FFC+
