180nm 5V Bandgap

特色

2.5V-5.5V operation.
3σ 4% untrimmed voltage reference accuracy.
2% variation over -40ºC to 125ºC after trimming.
70dB low frequency PSRR.
Trimmed, temperature compensated, 10µA reference current outputs with 3% accuracy.
Trimmed IPTAT output currents can be provided.
Less than 8µV noise from 0.1Hz to 10KHz.
3 bit voltage trimming.
4 bit current trimming.
-40°C to 140°C temperature operation.
Small cell area: 0.02mm2 in 0.15µ Vanguard International Semiconductor BCD process.
TSMC 180nm also available.
<0.2mW typical power dissipation.
