SRC-Lite : 16-bit -90dB THD+N Multi-Channel Audio Asynchronous Sample Rate Converter

The ASRC-lite (CWda50) is part of Coreworks family of multi-channel asynchronous Audio Sample Rate Converter (ASRC). This core can be used to interface digital audio equipments operating at different sample rates. It has been designed for systems that require a low-cost solution, maintaining low harmonic distortion and noise, and a high tolerance and rejection of input jitter.

The ASRC-lite can perform common sample rate conversions with less than -90 dB of Total Harmonic Distortion plus Noise (THD+N) and has a Dynamic range of 92 dB, supporting input data of 16-bit resolution.

The Coreworks ASRC series are implemented to support several key industry interfaces: TDM parallel, TDM serial, Parallel, I2S, SPDIF-AES3.

Coreworks offers a broad range of asynchronous sample rate converters targeted for variety of audio applications.
