Linear Low-Dropout Regulator (Output Voltage 0.6V)
1-VIA’s VSCOM4L400ALDO0V6 IP is a linear Low-Dropout (LDO) voltage regulator providing precise and programmable voltage regulation across a wide range of input and output voltages (610-750mV, 8 configurations with 20mV trimmability in each configuration) implemented in TSMC12/16nm CMOS FinFET technology.
The regulator architecture provides high Power Supply Rejection (PSR) and low noise making it suitable for analog and RF applications.
The regulator architecture provides high Power Supply Rejection (PSR) and low noise making it suitable for analog and RF applications.
查看 Linear Low-Dropout Regulator (Output Voltage 0.6V) 详细介绍：
- 查看 Linear Low-Dropout Regulator (Output Voltage 0.6V) 完整数据手册
- 联系 Linear Low-Dropout Regulator (Output Voltage 0.6V) 供应商
Block Diagram of the Linear Low-Dropout Regulator (Output Voltage 0.6V)
