The KEXP IP core performs AES key expansion, and is an option for the AES, AES-P and AES-GCM cores. It processes 128-bit blocks, and is programmable for 128-, 192-, and 256-bit key lengths.
Two architectural versions are available to suit system requirements. The Standard version is more compact, using a 32-bit datapath and requiring 44/52/60 clock cycles for each data block (128/192/256-bit cipher key, respectively). The Fast version achieves higher throughput, using a 128-bit datapath and requiring 11/13/15 clock cycles for each data block.
The KEXP core is a fully synchronous design and has been evaluated in a variety of technologies, and is available optimized for ASICs or FPGAs.
- Satisfies Federal Information Processing Standard (FIPS) Publication 197 from the US National Institute of Standards and Technology (NIST)
- Employs user-programmable key size of 128, 192 or 256 bits
- Two architectural versions:
- Standard is more compact: 32-bit data path size
- Fast yields higher transmission rates: 128-bit data path
- Suitable for use with AES cores
- Simple, fully synchronous, reusable design
- Available as fully functional and synthesizable VHDL or Verilog, or as a netlist for popular programmable devices
- Complete deliverables include test benches, C model and test vector generator
- HDL RTL source code (ASICs) or post-synthesis EDIF netlist (FPGAs)
- Sophisticated HDL Testbench (self checking)
- C Model & test vector generator
- Simulation script, vectors & expected results
- Synthesis script
- User documentation
- Protected network routers
- Electronic financial transactions
- Secure wireless communications
- Secure video surveillance systems
- Encrypted data storage
Block Diagram of the Key Expander Core
