HDMI 2.0 Transmitter

特色

Compliant with HDMI 2.0 specification and HDCP 1.4 Specification compliant
Supports high-definition video with up to 4K resolution
Support for up to 48-bit Deep Color
Supports industry-standard S/PDIF for digital audio using IEC 60958 2-channel PCM, and compressed (encoded) audio data (DTS, AC3, MPEG Audio) using IEC 61937 format
Support for I2S interface for multi-channel audio
Capable of carrying all InfoFrame including AVI, Audio, MPEC, SPD and others
Integrated High-Bandwidth Content Protection (HDCP) 1.4 for both video and audio
Serial Bus Slave Programming Interface
Receiver detection: supports Hot Plug Detection
DVI 1.0 compliant output
SMIC 65 nm and SMIC 130 nm processes
