HDMI 2.0 Receiver with MHL 2.0

特色

HDMI 2.0 Specification, MHL 2.0 Specification and HDCP 1.4 Specification compliant
4 HDMI input ports, of which one is MHL compliant
Deep color support – up to 48 bits
Selectable audio interface (S/PDIF or I2S) for digital audio output
3D audio output support – up to 32 channels
Full 3D HD video support
Embedded CEC PHY
Audio Return Channel support
Integrated Fractional PLL for Audio Clock Regeneration
Video resolutions – up to 4k2k at 60 Hz
RGB YCbCr 4:4:4/4:2:2/4:2:0 video format support
APB interface for MCU access support
Power-down mode support
