eDP 1.4 Receiver

特色

Compliant with Embedded DisplayPort 1.4 specification
Support for up to 4 Dual-Speed lanes at 1.62 Gbit/s and 2.7 Gbit/s
Supports Enhanced Framing Mode
Integrated High-bandwidth Digital Content Protection (HDCP) version 1.4
Integrated Audio Clock Regeneration
Deep-Color mode support up to 48-bit RGB/YCbCr Digital Video Output with selectable edge clocking
Power-down modes
2.5 V I/O
Panasonic 65 nm process
Supports Advanced Link Power Management
Supports GTC function
Supports Panel Self Refresh function
