DDR PHY & DDR CONTROLLER IP
特色
- DDR4/DDR3/DDR2 PHY IP fully compliant with the DFI 4.0 Specification.
- LPDDR5/LPDDR4/LPDDR3/LPDDR2 PHY IP fully compliant with the DFI 4.0 Specification.
- Support speeds up to 4266Mbps.
- IP is split into 2 hard macros.
- One for commands, control and address pins and another for 8-bit data bus.
- Can support custom number of address bits.
- Compensation controller and Pads are provided for automatic driver and receiver termination impedance calibration
- Features include slew rate control, Per-bit de-skew, gate training, read and write leveling.
- JTAG signals also provided for Mentor/Synopsys and LogicVision
- Built in Self Test with a Pseudo Random Pattern Generator
- Built with Scannable flops
- Can be used in wirebond, flip-chip and cup configurations
查看 DDR PHY & DDR CONTROLLER IP 详细介绍：
- 查看 DDR PHY & DDR CONTROLLER IP 完整数据手册
- 联系 DDR PHY & DDR CONTROLLER IP 供应商
Block Diagram of the DDR PHY & DDR CONTROLLER IP
