The Roa Logic AHB-Lite Timer IP is a fully parameterized soft IP implementing a user-defined number of timers and functions as specified by the RISC-V Privileged 1.9.1 specification.
The IP features an AHB-Lite Slave interface, with all signals defined in the AMBA 3 AHB-Lite v1.0 specifications fully supported, supporting a single AHB-Lite based host connection. Bus address & data widths as well as the number of timers supported are specified via parameters.
The timebase of the timers is derived from the AHB-Lite bus clock, scaled down by a programmable value.
The module features a single Interrupt output which is asserted whenever an enabled timer is triggered
- AHB-Lite Interface with programmable address and data width
- User defined number of counters (Up to 32)
- Programmable time base derived from AHB-Lite bus clock
- Full Source Code
- Compilation Scripts
Block Diagram of the AHB-Lite Timer
