AHB-Lite Multilayer Switch
The Roa Logic AHB-Lite Multi-layer Interconnect is a fully parameterized High Performance, Low Latency Interconnect Fabric soft IP for AHB-Lite. It allows a virtually unlimited number of AHB-Lite Bus Masters and Slaves to be connected without the need of bus arbitration to be implemented by the Bus Masters. Instead, Slave Side Arbitration is implemented for each Slave Port within the core.
The Multi-layer Interconnect supports Priority and Round-Robin based arbitration when multiple Bus Masters request access to the same Slave Port. Typically arbitration completes within 1 clock cycle
The Multi-layer Interconnect supports Priority and Round-Robin based arbitration when multiple Bus Masters request access to the same Slave Port. Typically arbitration completes within 1 clock cycle
查看 AHB-Lite Multilayer Switch 详细介绍：
- 查看 AHB-Lite Multilayer Switch 完整数据手册
- 联系 AHB-Lite Multilayer Switch 供应商
Block Diagram of the AHB-Lite Multilayer Switch
