800G Ethernet IP for AI Application
The Alphawave IP OmegaCORE 800G_AX is a cutting-edge solution with the latency, power, and area highly optimized for artificial intelligence applications. It supports the Physical Coding Sublayer (PCS) for 64B/66B, type 800GBASE-R function based on the IEEE 802.3bs/cd, Forward Error Correction (FEC), and Media Access Control (MAC) layer function. It supports a single-channel of 800GE or a combination of lower rates of 100GE, 200GE, and 400GE.
查看 800G Ethernet IP for AI Application 详细介绍:
- 查看 800G Ethernet IP for AI Application 完整数据手册
- 联系 800G Ethernet IP for AI Application 供应商
Block Diagram of the 800G Ethernet IP for AI Application
![800G Ethernet IP for AI Application Block Diagam](http://www.design-reuse.com/sip/blockdiagram/51166/20220808050450-main-800G_AX.png)
