14b 30kS/s serial ADC
特色
- Effective Number of Bits: 13.5b (SNDR=83dB signal-to-noise-and-distortion-ratio)
- Power supply 3.3V, Power Consumption 170µW
- 0.35um CMOS Technology
- Low input sampling capacitor of 4pF
- Pseudo differential analog voltage input (3 pins: Vin+, Vin- with adjustable common mode level Vcm)
- Layout chip area < 0,8mm²
- External clock rate 3-4MHz
查看 14b 30kS/s serial ADC 详细介绍：
- 查看 14b 30kS/s serial ADC 完整数据手册
- 联系 14b 30kS/s serial ADC 供应商
Block Diagram of the 14b 30kS/s serial ADC
